Clamshell

Clamshell blister packs



SHILOH PLASTICS MAKES & SUPPLIES CLAMSHELL PACKAGING

CLAMSHELL BLISTER PACKS

What is a Clamshell Blister Pack?

A clamshell totally encloses the product

A plastic clamshell is a packaging solution for products that can be hung from a hook. However unlike slide in card blister packs, it is made of one piece of plastic with a hinge in the middle. It closes up just like a clamshell, hence the name. To further explain what makes a clamshell, see our list of attributes that describes our clamshell range of blister packs:

  • Product is entirely enclosed in plastic blister pack
  • Front and back fold together as in a clamshell
  • Clamshell may have hanger hole punched in top
  • Large range of off-shelf sizes available or design your own.
  • Package clearly displays product
  • Samples available for cost of freight

See our product list below:

Below are lists of our clamshell range of blister packs arranged in three different orders to help you find what you’re looking for:

PRODUCT LIST:

Order by Length

Code Cavity Dimensions Card Size  (not included) Carton Quantity
PP9000 70 x 32 x 20 mm 63 x 26 mm 1,000
C753020 75 x 30 x 20 mm 73 x 28 mm 1,000
C754410 75 x 44 x 10 mm 67 x 37 mm 1,000
C704015 70 x 40 x 15 mm 71 x 41 mm 1,000
C806030 80 x 60 x 30 mm 131 x 52 mm 850
C853020 85 x 30 x 20 mm 105 x 27 mm 1,260
C955020 95 x 50 x 20 mm 97 x 52 mm 1,100
C955030 95 x 50 x 30 mm 97 x 52 mm 1,100
C1054525 105 x 45 x 25 mm 107 x 46 mm 950
C1056530 105 x 65 x 30 mm 96 x 63 mm 800
C1056550 105 x 65 x 50mm 93 x 59 mm 800
C10510530 105 x 105 x 35mm 100 x 100 mm 600
C10510550 105 x 105 x 50mm 93 x 93mm 540
C10810025 108 x 100 x 25 mm 142 x 100mm 600
C1178025 117 x 80 x 25 mm 121 x 85 mm 760
C1203525 120 x 35 x 25 mm 140 x 31 mm 1,050
C1207035 120 x 70 x 35 mm 117 x 67 mm 800
C14510025 145 x 100 x 25 mm 142 x 100 mm 600
C14511330 145 x 113 x 30mm 142 x 110mm 500
C14511350 145 x 113 x 50mm 142 x 110mm 500
C14814030 148 x 140 x 30mm 145 x 138mm 400
C14814050 148 x 140 x 50mm 145 x 138mm 300
C1604030 160 x 40 x 30 mm 184 x 39 mm 1,050
C17010020 170 x 100 x 20mm 170 x 100mm 400
C17010035 170 x 100 x 35mm 170 x 100mm 350
C1754030 175 x 40 x 30 mm 195 x 36 mm 1,260
C2004030 200 x 40 x 30 mm 195 x 36 mm 1,260
C2005835 200 x 58 x 35mm 200 x 58 mm 700
C2005855 200 x 58 x 55mm 200 x 58 mm 800
C2055035 205 x 50 x 35 mm 194 x 50 mm 500
C23012530 230 x 125 x 30 mm 230 x 126 mm 200
C23012550 230 x 125 x 50mm 230 x 123 mm    200
C23019525 230 x 195 x 25mm 230 x 197 mm 250
C23019550 230 x 195 x 50mm 225x190mm 250
C2505035 250 x 50 x 35 mm 250 x 47 mm 625

Order by Width

Code Cavity Dimensions Card Size (not included) Carton Quantity
C753020 75 x 30 x 20 mm 73 x 28 mm 1,000
C853020 85 x 30 x 20 mm 105 x 27 mm 1,260
PP9000 70 x 32 x 20 mm 63 x 26 mm 1,000
C1203525 120 x 35 x 25 mm 140 x 31 mm 1,050
C704015 70 x 40 x 15 mm 71 x 41 mm 1,000
C1604030 160 x 40 x 30 mm 184 x 39 mm 1,050
C1754030 175 x 40 x 30 mm 195 x 36 mm 1,260
C2004030 200 x 40 x 30 mm 195 x 36 mm 1,260
C754410 75 x 44 x 10 mm 67 x 37 mm 1,000
C1054525 105 x 45 x 25 mm 107 x 46 mm 950
C955020 95 x 50 x 20 mm 97 x 52 mm 1,100
C955030 95 x 50 x 30 mm 97 x 52 mm 1,100
C2055035 205 x 50 x 35 mm 194 x 50 mm 500
C2505035 250 x 50 x 35 mm 250 x 47 mm 625
C2005835 200 x 58 x 35mm 200 x 58 mm 700
C2005855 200 x 58 x 55mm 200 x 58 mm 800
C806030 80 x 60 x 30 mm 131 x 52 mm 850
C1056530 105 x 65 x 30 mm 96 x 63 mm 800
C1056550 105 x 65 x 50mm 93 x 59 mm 800
C1207035 120 x 70 x 35 mm 117 x 67 mm 800
C1178025 117 x 80 x 25 mm 121 x 85 mm 760
C10810025 108 x 100 x 25 mm 142 x 100mm 600
C14510025 145 x 100 x 25 mm 142 x 100 mm 600
C17010020 170 x 100 x 20mm 170 x 100mm 400
C17010035 170 x 100 x 35mm 170 x 100mm 350
C10510530 105 x 105 x 35mm 100 x 100 mm 600
C10510550 105 x 105 x 50mm 93 x 93mm 540
C14511330 145 x 113 x 30mm 142 x 110mm 500
C14511350 145 x 113 x 50mm 142 x 110mm 500
C23012530 230 x 125 x 30 mm 230 x 126 mm 200
C23012550 230 x 125 x 50mm 230 x 123 mm    200
C14814030 148 x 140 x 30mm 145 x 138mm 400
C14814050 148 x 140 x 50mm 145 x 138mm 300
C23019525 230 x 195 x 25mm 230 x 197 mm 250
C23019550 230 x 195 x 50mm 225x190mm 250

Order by Depth

Code Cavity Dimensions Card Size  (not included) Carton Quantity
C754410 75 x 44 x 10 mm 67 x 37 mm 1,000
C704015 70 x 40 x 15 mm 71 x 41 mm 1,000
PP9000 70 x 32 x 20 mm 63 x 26 mm 1,000
C753020 75 x 30 x 20 mm 73 x 28 mm 1,000
C853020 85 x 30 x 20 mm 105 x 27 mm 1,260
C955020 95 x 50 x 20 mm 97 x 52 mm 1,100
C17010020 170 x 100 x 20mm 170 x 100mm 400
C1054525 105 x 45 x 25 mm 107 x 46 mm 950
C10810025 108 x 100 x 25 mm 142 x 100mm 600
C1178025 117 x 80 x 25 mm 121 x 85 mm 760
C1203525 120 x 35 x 25 mm 140 x 31 mm 1,050
C14510025 145 x 100 x 25 mm 142 x 100 mm 600
C23019525 230 x 195 x 25mm 230 x 197 mm 250
C806030 80 x 60 x 30 mm 131 x 52 mm 850
C955030 95 x 50 x 30 mm 97 x 52 mm 1,100
C1056530 105 x 65 x 30 mm 96 x 63 mm 800
C14511330 145 x 113 x 30mm 142 x 110mm 500
C14814030 148 x 140 x 30mm 145 x 138mm 400
C1604030 160 x 40 x 30 mm 184 x 39 mm 1,050
C1754030 175 x 40 x 30 mm 195 x 36 mm 1,260
C2004030 200 x 40 x 30 mm 195 x 36 mm 1,260
C23012530 230 x 125 x 30 mm 230 x 126 mm 200
C1207035 120 x 70 x 35 mm 117 x 67 mm 800
C10510530 105 x 105 x 35mm 100 x 100 mm 600
C17010035 170 x 100 x 35mm 170 x 100mm 350
C2005835 200 x 58 x 35mm 200 x 58 mm 700
C2055035 205 x 50 x 35 mm 194 x 50 mm 500
C2505035 250 x 50 x 35 mm 250 x 47 mm 625
C10510550 105 x 105 x 50mm 93 x 93mm 540
C1056550 105 x 65 x 50mm 93 x 59 mm 800
C14511350 145 x 113 x 50mm 142 x 110mm 500
C14814050 148 x 140 x 50mm 145 x 138mm 300
C23012550 230 x 125 x 50mm 230 x 123 mm    200
C23019550 230 x 195 x 50mm 225x190mm 250
C2005855 200 x 58 x 55mm 200 x 58 mm 800
